Griddle/Hotplate
18 mj burners with pilot, FFD and piezo ignition
Variable flame control valve with low flame setting
16mm thick mild steel griddle plate
Top weld sealed hotplate sections
CS-9P plate: 890mm x 540mm; 0.48m2 cooking area
2mm 304 stainless steel splash guards
Griddle oil tray 1.2mm stainless steel
Overall Construction
Heavy duty construction
Welded 1.2mm 304 stainless steel front hob
Front and side panels 0.9mm 304 stainless steel
Splashback 1.2 mm 304 stainless steel
Stainless steel legs with 55mm height adjustment range
Gas Rating: Nat 54mj / LPG 54mj
24 Month ‘Platinum Warranty’
Australian Made
Dimensions (mm): 900w x 800d x 1100h
Connections
Gas 3/4” BSP male
180mm from right, 50mm from rear, 600mm from floor
Supplied with gas regulator (specify Nat or LP on order)
Cleaning & Servicing
Easy access to all parts & components from front
