Waterless Wok

90 mj 24 jet chimney burners with pilot & FFD
405mm diameter standard size cast-iron wok ring
Air gap cooling system
Quarter turn water control lever
Folding rear laundry arm with front panel controls
Wider front gutter design for easier cleaning
Internal front heat shield panel
Supplied with waste strainer
Zinc-aluminium Alloy burner handles

Heavy duty construction
Full skirt, enamelled cast-iron rings
1.5mm 304 stainless steel one-piece pressed deck
0.9mm 304 stainless steel condiment shelf
Splashback and front cover 1.2 mm 304 stainless steel
Integrated hob 1.5mm 304 stainless steel
Side panels 1.2mm 304 stainless steel
Undertrays 0.9mm stainless steel
Stainless steel removable legs
30mm height adjustment range

650mm x 800mm x 1300mm H
Working height 800mm
Weight 95kg
Packed dimensions 710mm x 900mm x 1460mm H
Packed weight 123kg

Gas 3/4” BSP Female
Gas 61mm from right, 84mm from rear, 425m to floor
Supplied with gas regulator (specify Nat or LP on order)
Water inlet 1/2” copper tube
Water 140mm from right, 81mm to rear, 408mm to floor
Drain 1/1/4” BSP male
Drain 122mm from right, 83mm from rear, 590mm to floor
Cleaning & Servicing

Easy access to all parts & components from front

Knee lever timer tap
Replace Duckbill burner with Chimney Dual Ring burner (110mj)
Replace Standard Duckbill burner with High Output 28 inj
Duckbill burner (145MJ)
250mm and 500mm wide clip on shelves (front)
Wok Holder
Clip On Sauce Holder
Injector Cleaning Tool
Joining caps & strips
RH and LH side shields
Rear castors
